BQ1226/15E Hydraulic Single Spindle Rotary Peeling Lathe

Using: BSY Brand Heavy duty Hydraulic Single Spindle Wood Veneer Peeling Lathe is developed for large diameter log peeling, it can peel log above 600mm diameter, Max for 1500mm diameter. The machine use A/C motor as main motor, D/C motor for option. The machine is with nose bar, suitable for face veneer production.

Key words：

SHANDONG BAISHENGYUAN

Category ：

Hydraulic Spindle Rotary Peeling Lathe

E-mail：

sdbsygroup@aliyun.com

PRODUCT MESSAGE

RELATED PRDUCTS

Main technical parameters

MODEL	BQ1226/15E	BQ1226/13E	BQ1215/15E	BQ1215/13E
Maximum peeling diameter	φ1500mm	φ1300mm	φ1500mm	φ1300mm
Final log core diameter	φ220mm	φ220mm	φ220mm	φ220mm
Peeling length	1900~2700mm	1900~2700mm	900~1450mm	900~1450mm
Peeling veneer thickness range	0.35~3.4mm	0.35~3.4mm	0.35~3.4mm	0.35~3. .4mm
Spindle diameter	φ200mm	φ200mm	φ200mm	φ200mm
Spindle speed	0~160rpm	0~160rpm	0~160rpm	0~160rpm
Knife table fast feeding speed	2.2m/min	2.2m/min	2.2m/min	2.2m/min
Main motor power	98kW ( 75kW,high and low)	98kW ( 75kW,high and low)	55kW,high and low	55kW,high and low
Fast feeding motor power	5.5kW	5.5kW	5.5kW	5.5kW
Kni fe servo motor power	1.5kW	1.5kW	1.5kW	1.5kW
Rear angle motor power	0.75kW	0.75kW	0.75kW	0.75kW
Hydraulic station motor power	7.5kW	7.5kW	7.5kW	7.5kW
Knife grinding angle	18°~22°	18°~22°	18°~22°	18°~22°
Machine total power	118.75kW ( 93.25kW,high and low)	118.75kW ( 93.25kW,high and low)	71.35kW	71.35kW
Machine size	9500×2340×2200mm	9500×2280×2200mm	7850×2340×2200mm	7850×2280×2200mm
Weight	26300kg	26000kg	22300kg	22000kg

Features:

Good rigidity,high strength
With precision ball feeding screw,ensure the blade carriage for feeding accuracy
With hydraulic press blade,convenient to assemble the blade,improve production efficiency,lower the intensity of labor
With hydraulic clamping,can adjust hydraulic cylinder press of chuck spindle automatically according to different soft and hard wood
DC Motor

The detail images:
